1030nm ultrafast laser dedicated hollow core polarization-maintaining fiber jumper (with FC connector, customizable wavelength)

1030nm ultrafast laser dedicated hollow core polarization-maintaining fiber jumper (with FC connector, customizable wavelength)

Hollow core fiber patch cables for ultrafast laser beam delivery. These polarization-maintaining fiber patch cables are ideal for nonlinear imaging optical coherence tomography (OCT), distortion-free ultrafast laser fiber delivery, sensors, and spectroscopy applications.

Product features：Hollow core fiber with custom wavelengths、 Near single-mode fiber guidance、 Broad spectral range、 Low dispersion, low loss、 Standard connectors、 Custom options: alignment, coupling and collimation

Part Number：--

Application area：

Add to Cart Consult Favorite

Related Products

Main parameters
General Parameters
Optional Configurations
Downloads

Main parameters

Core parameters

Dimension Drawing

General Parameters

Polarization-Maintaining Fiber Patch Cables with FC Connectors

Parameter

Physical properties
Patch cord length	2,3,5m⁽¹⁾
Connector	FC, SMA⁽¹⁾
Drum diameter	6mm
Optical properties
Center wavelength	532nm; 800m; 1030nm; 2μm⁽¹⁾
Transmission efficiency	>90%
Fiber mode field diameter (1/e”)	The specific parameters depend on the optical fiber.
Input energy at 100fs	<1μJ.
Input power	<5W

1) customizable

Optional Configurations

Downloads

No resources available
