    • 780nm 30mW Coaxial Packaging Single-Mode Fiber Coupled Laser

    The LP-780SM-FA-C series coaxial single-mode fiber coupled laser is a low-loss single-mode fiber coupled laser introduced by Idealphotonics . It features a compact packaging size and high output power. Our products are widely used in laser communication, printing, and laser medical fields.

    产品特点Wavelength: 780nm、 Single-mode fiber、 Coaxial package、 Built-in detector

    产品货号A80021010

    应用领域Medical field、 Printing、 Fiber laser systems

    产品单价联系客服询价

    到货日期请咨询客服获得货期

    产品库存请咨询客服

    Daisy

    电话：18602170419

    邮箱：moli@microphotons.com

    加入询价单 在线咨询

    收藏

    相关产品

    主要参数
  • 核心参数

  • 尺寸图

    • Parameters

    Parameters

    Value

    Center wavelength (nm)

    780±5nm

    Continuous output power (mW)

    >30mw

    Spectral width

    0.5-2nm

    Fiber core

    6um

    Numerical aperture (NA)

    0.12

    Fiber length

    0.8m

    Connector

    FC/APC

    Operating voltage

    1.8-2.3V

    Threshold current

    35mA

    Maximum operating current

    140mA

    Monitoring current

    0.5mA

    Differential efficiency

    0.9mw/mA

    PD reverse breakdown voltage

    30V

    Package type

    Coaxial package





    pin definition



    1

    LD+

    2

    LD-/PD+

    3

    PD-
