ETALON Thermally Stable Transmission Filter (1525-1565nm 50GHz Fineness 14)

Idealphotonics' thermally stable filters are based on advanced ETALON technology, and use unique optical and mechanical designs and advanced packaging technology to ensure the stability of the wavelength of this filter under extreme environmental conditions, including temperature and humidity. We have unique technical approval technology to ensure that the target accuracy of the wavelength of this filter is within ITU +/-1.25GHz in all environments. This ITU-aligned filter can be used for channel monitoring and wavelength locking in wavelength division multiplexing (WDM) systems. We also have special technologies for customers to select the accuracy corresponding to a specific wavelength. This filter is divided into transmission and reflection according to different usage methods. The unique design can ensure that the fineness of the standard tool, channel spacing and operating wavelength have a wide range of choices. The thermally stable filter designed for customers is well compatible with a variety of spectral applications, including telecommunications, wavelength reference and calibration and fiber optic sensing systems, test and measurement, and laser wavelength stabilization control.

产品特点Excellent thermal stability、 Low insertion loss、 Strong packaging、 One-end fiber outlet for easy fiber winding

产品货号A80150462

应用领域FBG sensing system Monitoring system、 Test and measurement equipment、 Instrumentation
