1550nm narrow linewidth single-frequency semiconductor laser module 10mW

The Idealphotonics narrow linewidth single-frequency laser features a unique semiconductor external cavity structure. The typical output bandwidth is less than 3 kHz, and its wavelength is less sensitive to vibrations. This device offers a high side-mode suppression ratio, low relative intensity noise, and excellent wavelength stability, making it suitable for various applications in harsh environments. The Idealphotonics narrow linewidth single-frequency laser has proprietary patents, with high structural stability and mature technology, making it ideal for mass production. This product complies with the Telcordia GR-468 standard and has passed long-term reliability testing.

产品特点Polarization-maintaining fiber output, linewidth less than 3 kHz、 Low phase noise and relative intensity noise、 Stable structure with low sensitivity to vibrations、 ITU-T wavelengths from 1530 to 1565 nm, customizable upon request、 Operating temperature range: 0 to 70°C、 Complies with Telcordia GR-468 standard

产品货号A80112001

应用领域LiDAR、 Fiber Optic Hydrophone、 Resonant Fiber Optic Gyroscope、 Distributed Fiber Optic Sensing、 Coherent Communication、 Scientific Research
