In-line Polarization Controller, 1310nm SMF-28e fiber

In-line Polarization Controller, 1310nm SMF-28e fiber

Low insertion loss, high return loss, high operating power, epoxy-free optical path. Product applications: PM testing systems, laboratory testing.

Product features：Low insertion loss 、 High return loss 、 High operating power 、 Epoxy-free optical path 、 PM testing systems 、 Laboratory testing

Part Number：--

Application area：Display panel testing 、 LED lighting flicker analysis 、 Toy light flicker frequency and power measurement 、 Gas analysis

Add to Cart Consult Favorite

Related Products

Main parameters

Core parameters

Dimension Drawing

General Parameters

Main Parameters

Parameters	Index
Operating Wavelength	1310 or 1550
Bandwidth	±20nm
Insertion loss	≤1.0dB
Degree of Polarization (DOP)	≤ 10%
Return loss	≥50dB
Fiber type	Input: Polarization-maintaining fiber
Fiber type	Output: Single-mode fiber
Optical power	≤ 500mW
Polarization direction	Polarized light emitted to the slow axis of the input PM fiber
Operating temperature	-5 to +70°C
Operating temperature	-40 to +85°C
Package size	B= Ø 5.5 x L56

Note:

High-power handling products can be provided upon request.

For devices with connectors, insertion loss will increase by 0.3 dB, and return loss will decrease by 5 dB.

Port Configuration

Model Example

Optional Configurations

Downloads

In-line Polarization Controller, 1310nm SMF-28e fiber.pdf
