10m optical path miniaturized gas chamber 1960-2400nm

The 10-meter optical input and electrical output gas absorption cell is used for various gas spectral analysis and detection. The optical path structure of the gas cell uses the self-patented design, the flat wave gas cell (SlimBoss Gas Cell) with excellent optical stability, and the auxiliary and high-stability optical packaging structure, which is mainly composed of the gas cavity, reflector, standard optical fiber connector, gas inlet and outlet, and shockproof base. The unique suspension optical path design has excellent vibration and temperature stability, can work stably in various complex environments, and is very suitable for online real-time detection of various gases. It has low system noise and can be applied to trace gas analysis..

产品特点The air chamber structure is stable and resistant to vibration and external extrusion、 The air chamber is small in size, compact in structure, and easy to carry、 The effective optical path is long、 The input uses standard single-mode optical fiber, and the output uses PD or optical fiber

产品货号H80060002

应用领域Air pollutant monitoring、 Coal flue gas emission monitoring、 Waste incineration emission monitoring、 Chemical park pollutant monitoring
