• Polyimide-coated Ge-doped high-temperature-resistant single-mode fiber

    Compared with ordinary single-mode optical fibers, this product uses a polyimide (PI) coating. Polyimide is a polymer material with excellent comprehensive properties, featuring high heat resistance, excellent dielectric properties, and good mechanical strength. It can greatly improve the temperature resistance of the optical fiber coating and extend the service life of the optical fiber in high-temperature environments.

    产品特点High-temperature resistance 、Durability, high bending strength, and sealing performance 、Enables the welding of embedded optical fibers, fiber bundles, and pigtails into high-vacuum environments

    产品货号C80010119

    应用领域High-temperature environments 、Harsh chemical environments 、Nuclear radiation environments 、High-power laser transmission 、Medical applications 、Optical fiber bundle welding

    产品单价联系客服询价

    到货日期请咨询客服获得货期

    产品库存请咨询客服

    Sherry

    电话:16628709332

    邮箱:moli@microphotons.com

    主要参数
  • 核心参数
  • 尺寸图
  • Process Advantages

    High-quality coating layer, no deformation at 300℃, adjustable coating thickness;



    Our company uses a specially designed vertical online thermosetting process, which allows for a large adjustable range of coating thickness, good concentricity of the fiber coating layer, and a smooth coating surface that avoids stress concentration points, significantly improving the selection strength. At the same time, the curing is uniform, reducing glue residue. In our 300℃ high-temperature thermal shock test, the fiber does not bend or deform, maintaining excellent bending and tensile strength after prolonged high-temperature exposure;



    High-speed preparation of low-loss optical fibers;



    Polyimide, unlike acrylate light-curing methods, requires a thermosetting process that has a longer curing time, resulting in a slower fiber drawing speed compared to conventional acrylate drawing, which can increase fiber loss during the longer drawing process;



    Based on the online continuous thermoplastic/thermosetting process with a longer fiber run and specially modulated PI coatings, our process can achieve excellent coating quality at higher drawing speeds, significantly improving the preparation efficiency of high-temperature resistant fibers and increasing the consistency of the fiber's geometric parameters. By applying multi-stage, multi-parameter PI materials, we achieve thicker PI coatings and lower single-mode fiber losses by adjusting the physical and chemical properties of the inner, middle, and outer layers of materials.




    Industry Applications and Operating Environments

    Medical industry; mining industry, oil and gas industry; aerospace industry, nuclear industry; chemical industry; optical communication industry; power industry; high temperature, high pressure, and low temperature environments; electromagnetic radiation environment; underwater use, resistant to hydrolysis; medical interventional therapy, with biocompatibility; can be ETO and radiation sterilized (pure silica core).



    Parameter

    Property

    Cut-off wavelength

    ≤1260 nm

    Mode Field Diameter

    @1310 nm 9.2 ± 0.4 µm

    @1550 nm 10.4 ± 0.8 µm

    Attenuation Coefficient

    @1310 nm 0.7dB/km

    @1550 nm 0.7dB/km

    Parameter

    Delivery length

    1 - 30 km

    Cladding diameter

    125 ± 1 µm

    Coating diameter

    155 ± 5 µm

    Core-clad concentricity

    ≤0.6 µm

    Cladding non-circularity

    ≤0.1

    Coating material

    Polyimide

    Long-term operating temperature

    -55 - 300 ℃

    Short-term tolerance temperature

    400 ℃

    Screening strength

    100 - 200 kpsi
