1480nm High-Power Benchtop Single-Mode Pump Source 500mW

IdealPhotonics' 1480nm high-stability single-mode pump light source uses a single-mode semiconductor laser with an FBG wavelength-stabilized grating, which has a stable wavelength and high output power. The control system based on advanced microprocessors, combined with high-precision ATC and ACC (APC) control circuits, achieves high-stability output of the laser, while ensuring that the light source is quick and intuitive to operate. We can also provide corresponding communication interfaces and control software according to user requirements to achieve computer control. This light source uses the Turn-Key pump laser protection function to effectively prevent customers from operating it incorrectly. The power can be roughly adjusted (stepped by 50mW) or finely adjusted by 0.1mW. IdealPhotonics' 1480nm single-mode pump light source is a highly integrated desktop system light source with a high-definition LCD display, continuously adjustable output power, and synchronous display of current and voltage, which is very suitable for experimental scientific research and production testing. In addition, the company can also provide modular packaging according to user requirements to facilitate system integration.

产品特点Single-mode high-power output: up to 500mW、 FBG grating wavelength locking, no drift、 ASE optical isolation protection design、 Stable and continuously adjustable output power、 LCD status display、 High-precision ACC and ATC control circuits、 Optional built-in isolator

产品货号B80020027

应用领域Pump laser、 Dense Wavelength Division Multiplexing (DWDM)、 Compact packaged EDFA、 High bit-rate, high-channel-count EDFA、 Cable television distribution
