首页 Light Sources Coherent Sources Pump light source Multi mode fiber coupled high-power pump laser 793/808/915/976nm 915nm High Power Benchtop Multimode Pump Laser 5W

    • 915nm High Power Benchtop Multimode Pump Laser 5W

    The MHPL-XXX high-power laser source is based on high-performance semiconductor laser chips, with output coupled to 105/125um multimode optical fibers. The laser is designed with a constant current drive and temperature control circuits to ensure stable and safe operation. Some models feature wavelength locking, providing spectral stability within ±3nm. This laser source is suitable for applications in medical research, fiber laser pumping, and other production testing processes. It is available in both desktop and modular packaging and comes with PC-based monitoring software

    产品特点High Output Power、 Stable Power and Spectral Performance、 Available in Modular or Desktop Packaging

    产品货号B80020103

    应用领域Fiber Laser Pumping、 Biomedical Applications、 Material Laser Processing

    产品单价联系客服询价

    到货日期请咨询客服获得货期

    产品库存请咨询客服

    Daisy

    电话：18602170419

    邮箱：moli@microphotons.com

    加入询价单 在线咨询

    收藏

    相关产品

    主要参数
  • 核心参数

  • 尺寸图

    • Parameters

    Parameter

    Unit

    Typ.

    Notes

    Operating Wavelength

    nm

    793/808/976

    915


    Wavelength Accuracy

    nm

    ±3

    ±10


    Spectral Width

    nm

    3

    6


    Operating Mode

    -

    CW

    Continuous Light

    Output Power

    W

    5、10、25

    Customizable

    Short-Term Stability (15 min)

    dB

    ≤ ±0.02

    Equivalent≤±0.5%

    Long-Term Stability (8 h)

    dB

    ≤ ±0.05

    Equivalent≤±1.2%

    Pigtail Type

    -

    105/125μm Multimode Fiber，NA= 0.22


    Pigtail connector type

    -

    Bare Fiber

    Optional Fiber Collimator



    Electrical and Environmental Parameters

    Benchtop

    Module

    Control Method

    Keypad

    RS232 Serial Communication

    Communication Interface

    Optional

    DB9 Female

    Power Supply

    100~240VAC, <120W

    12V DC, <60W

    Dimensions

    260(W)×320(D)×120(H)mm

    125(W)×150(D)×30(H)mm

    Operating Temperature Range

    -5~+35°C

    Operating Humidity Range

    0~70%







    Ordering Info

    Ordering info/PN#

    MHPL

    Operating Wavelength(nm)

    Output Power(W)

    Output Pigtail Type

    Package Type

    793/808/915 /976/1064

    5/10/25

    MM=105/125μm Multi-mode Fiber

    B=Benchtop M=Module
