    • 1570nm Wavelength SM Fiber Coupled Laser, 30dBm

    The 1570nm single-wavelength laser adopts a high-performance butterfly semiconductor laser chip, with a professionally designed driver and temperature control circuit to ensure safe operation, stable output power, and spectral stability. It is suitable as a pump laser source for thulium-doped fiber lasers or fiber amplifiers and is available in both benchtop and module packaging.

    产品特点1~10W multiple power options、 Single-mode fiber output、 Various spectral options available

    产品货号A80100059

    应用领域Thulium-doped fiber laser、 Fiber laser、 Fiber sensing

    产品单价联系客服询价

    到货日期请咨询客服获得货期

    产品库存请咨询客服

    Daisy

    电话：18602170419

    邮箱：moli@microphotons.com

    加入询价单 在线咨询

    收藏

    相关产品

    主要参数
  • 核心参数

  • Center wavelength Output power Fiber optic connector

  • 尺寸图

    • Parameters

    Optical Specifications

    Unit

    Typ.

    Notes

    Operating Wavelength

    nm

    1570±1


    Spectral Linewidth

    nm

    < 0.1


    Side Mode Suppression Ratio (SMSR)

    dB

    >50


    Operating Mode

    -

    CW

    Continuous Wave

    Output Power

    dBm

    10/20/30/33/37/40


    Short-term Stability (15 minutes)

    dB

    ≤ ±0.02

    Equivalent≤±0.5%

    Long-term Stability (8 hours)

    dB

    ≤ ±0.05

    Equivalent≤±1.2%

    Pigtail Type

    -

    SMF-28 fiber


    Pigtail Connector Type

    -

    FC/APC




    Electrical and Environmental Parameters

    Benchtop

    Module

    Control Mode

    Button Control

    RS232 Serial Communication

    Communication Interface

    Optional

    DB9 Female

    Power Supply

    100~240VAC,<150W

    5V DC,<60W

    Dimensions

    260(W)×320(D)×120(H)mm

    125(W)×150(D)×20(H)mm

    Operating Temperature Range

    -5~+35°C

    Operating Humidity Range

    0~70%




    Ordering info

    PN#

    FL

    Operating wavelength(nm)

    Output Power(dBm)

    Output fiber tupe

    Package type


    1570

    10/20/30/33/37/40

    SM= SMF-28 PM=PM1550

    B=Benchtop

    M=Module

    *33~40dBm  only benchtop available
